Energy conservation hand type induction heating machine for welding heattreatment ,forging quenching ,full boiling
Advantage:
1 More than 17 years experience,stable and goods performance
2 CE certificated
3 Copperated with CHOW TAI FOOKS, Matsushita,Foxconn, Media, Gree and ZHIGAO Air conditioner.
4 Suitable for a large range, heating, quenching, forging, melting, solding and so on.
5 2 Transformer ratios more options connect induction coil
6 Coaxial Connection Flexible, can handle the flexible to work the workpiece that normal coil can not get it.
Main characteristics:
1 Siemens IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
2 100% Duty cycle, continuous working is allowed at maximum power output.
3 Display of heating power and heating current and oscillating frequency;
4 Simple to install, Installation can be done by unprofessional person very easily;
5 Light weight
7 Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;
Packing Photos:
| Type | HF-40KW |
| Work Power | 3*380v/415v/440v/480v 50-60hz |
| The range of operating voltage | 340-430V AC |
| Output power | 40KW |
| Input current | 40A |
| Fluctuating frequency | 30-80khz |
| Timing (Heat time,Retain time,Cool time) | 1-99S |
| The flow rate of cooling water | 0.15 Mpa 9L/Min |
| Water temperature protection point | 40centidegree |
| Duty cycle | 100% (40degree room temperature) |
| Weight | Mainparts:32Kg+28KG |
| Size | Main Parts:560*230*480mm Transfromer Part: 460*265*440MM |
